| Part Number | Description | Related Products |
|---|---|---|
| NU1520 | NU1520 integrates 32bit 36MHz MCU core, SRAM and Flash which contains Application ROM, Security Protection ROM. NU1520 integrates programmable system clock source which supports 8/16/24MHz external crystal input or 8 MHz internal oscillator. NU1520 supports 64 kHz internal low-power oscillator for Watchdog Timer and idle wake-up. 6 pins of NU1520 can be configured as interrupt source with edge detection, 4 I/O pins have wakeup function. NU1520 provide 4 channels 32-bit timers with one 5-bit pre-scalar independent clock source for each timer. NU1520 provides continuous capture function which can continuously capture rising, falling, both rising and falling edge on one signal. | Products > Wireless Charger > Wireless Charging Transmitter > |
| Part Number | Description | Related Products |
|---|---|---|
| NU2111A | The NU2111A is a highly efficient, 7-A battery charging/discharging solution, employing switched cap and compatible bypass architectures. The switched cap architecture and integrated FETs are optimized for a 50% duty cycle, halving the cable current compared to the current delivered to the battery. This effectively minimizes losses over the charging cable and limits temperature rise in the application. Additionally, the dual-phase structure reduces both input capacitance requirements and output voltage ripple, enhancing overall performance. | Products > Charger and BMS > Charger Pump > |
| Part Number | Description | Related Products |
|---|---|---|
| NU6801 | The NU6801 is a power management IC that features charging and discharging functions along with 3-port path management. It supports a wide range of VBUS voltage. When configured in charging mode, it can support a maximum input charging voltage of up to 16V. In discharging mode, it can support maximum output discharge voltage of up to 19V. It also integrates IBUS, IBAT, IAC, VBUS, VBAT and NTC signal sampling function. These features make the chip achieve highly customizable configurations and good compatibility. The NU6801 significantly reduces the number of external components and the layout area while maintaining high performance. The device is available in a thermally enhanced 4mm × 4mm QFN package. | Products > Charger and BMS > Switching Charger > |
| Part Number | Description | Related Products |
|---|---|---|
| NU6805 | The NU6805 is a high-efficiency, synchronous bidirectional buck-boost charge-discharge Copyright © 2024 NuVolta Technologies Inc. controller designed for managing 1- to 4-cell battery systems. It integrates a 4-switch architecture driver to support buck, boost, and buck-boost modes, enabling efficient power conversion across input voltages ranging from 4V to 24V while in charging mode, and output voltage from 3 to 22V in discharging mode. With a maximum input and output power of 100W, the device offers flexible input/output path management, programmable current/voltage limits via I²C interface, and robust protection features. The NU6805 is ideal for applications requiring bidirectional power flow, such as power banks, industrial equipment, and rechargeable battery systems. | Products > Charger and BMS > Switching Charger > |
| Part Number | Description | Related Products |
|---|---|---|
| NU1677 | NU1677 is a highly integrated and efficient wireless power receiver and suitable for up to 30W output power application. It integrates a synchronous rectifier and a programable low drop-out regulator. The regulator can provide a wide range regulated voltage. NU1677 can conduct bi-directional communication with a transmitter system through ASK and FSK. The communication is compliant with WPC Qi2.2 spec. NU1677 can also be operated as a transmitter (Tx) to charge another receiver. | Products > Wireless Charger > Wireless Charging Receiver > |
