NU1679 is a highly integrated and efficient wireless power receiver and suitable for up to 80W output power application. It integrates a synchronous rectifier and a programable low drop-out regulator. The regulator can provide a wide range regulated voltage. NU1679 can conduct bi-directional communication with a transmitter system through ASK and FSK. The communication is compliant with WPC. NU1679 can also be operated as a transmitter (Tx) to charge another receiver.
NU1679’s flexibility is provided by an on-chip 32-bit MCU which can customize and optimize the device for various applications and custom needs. The programmability includes output power, bidirectional communication scheme, system protection, status reporting, and error reporting.
NU1679 includes standard protections such as input under-voltage lockout, short-circuit protection, overvoltage protection, over-current protection, and overtemperature protection.

NU1677 is a highly integrated and efficient wireless power receiver and suitable for up to 30W output power application. It integrates a synchronous rectifier and a programable low drop-out regulator. The regulator can provide a wide range regulated voltage.
NU1677 can conduct bi-directional communication with a transmitter system through ASK and FSK. The communication is compliant with WPC Qi2.2 spec.
NU1677 can also be operated as a transmitter (Tx) to charge another receiver.

NU2135 is a 98.0% efficient, 9-A battery charging solution using a switched cap architecture. This architecture and the integrated FETs are optimized to enable a 50% duty cycle, allowing the cable current to be half the current delivered to the battery, reducing the losses over the charging cable as well as limiting the temperature rise in the application. The dualphasearchitecture reduces the input cap requirements as well as reducing the output voltage ripple.

NU17123 are a high efficiency, high integration Qi2 compliant transmitter IC for wireless charging.
NU17123 integrate low Rdson Full bridge FETs and gate driver, 32bit 36MHz MCU core, 8KB SRAM and 128KB Flash, and fast charging block TCPC/PD/BC1.2/QC3.0/UFCS/FCP/SCP/AFC.
NU17123 integrate all critical functions of power system, such us low -EMI FET drivers, Bootstrap circuits for external resonant capacitor switches, 4.8V/3.3V/1.5V LDO and 5V Buck converter power supply, high -accuracy current measurement. Controllable slew rate/ dead time of gate driver and PWM frequency dither function can further reduce the EMI of power system.
