• 97.5% Efficient at 2:1 charge mode, 99.2% Efficient at 1:1 charge mode

• Switched Cap Architecture Optimized for 50% Duty Cycle.

- Input Voltage is 2x Battery Voltage (3.5 V to 4.65v)

- Output Current is 2x of Input Current (Up to 4.5 A)

- Reduces Power Loss Across the Cable

• Support charge pump 2:1 and 1:1 charge mode

• Integrated Programmable Protection Features for Safe Operation

- Input Over-Voltage Protection (BUS_OVP) - Input Over-Current Protection (BUS_OCP) with Adjustable Alarm

- Input Over-Voltage with External OVP FET (VAC_OVP up to 17V)

• Battery Over-Voltage Protection (BAT_OVP) with Adjustable Alarm

- Output Over-Voltage (VOUT_OVP)

- IBAT Over-Current Protection (BAT_OCP) with Adjustable Alarm

- Battery Temperature Monitoring - Connector Temperature Monitoring

 • Programmable Settings for System Optimization

- Optional VBATERG and IBATERG Regulation for System Load and Wall Adapter Transients

- STAT, FLAG, and MASK options for Interrupts - ADC Readings and Configuration

 • Integrated 12-Bit Effective Analog-to-Digital Converter (ADC)

- ±1% BUS Voltage

- ±1% VOUT Voltage

- ±0.5% BAT voltage with Differential Sensing

- +2%/-4% BAT Current at 6 A with External 2mΩof RSENSE

- +1%/-1.5% BAT and BUS Temperature

- ±5℃ Die Temperature

• Smart Phone

• Tablet PC
