| Part Number | Description | Related Products |
|---|---|---|
| NUQ3240 | The NUQ3240 is a synchronous buck-boost controller suited for driving silicon MOSFET or Gallium Nitride (GaN) power transistors in highly efficient power converters. It supports wide input and output range up to 45V with seamless transitions between buck, buck-boost and boost modes. The NUQ3240 integrates both high side and low side gate drivers with UVLO protections. It provides programmable inductor peak current limit and output current limit functions with output instant current monitoring capability through ISMON. The CC/CV regulation capability allows it to be fitting in battery charging systems. The NUQ3240 supports ultra-wide switching frequency range from 50KHz up to 3MHz and integrates frequency spread spectrum (FSS) for EMI optimization. Optional external clock synchronization function facilitates the parallel operation. It also features external compensation, programmable soft-start to reduce the inrush current during start up. The NUQ3240 is available in 5mmx5mm 32-lead QFN package. | Products > Automotive > Auto DC/DC > |
| Part Number | Description | Related Products |
|---|---|---|
| NU17182 | - 3.3V – 36V input voltage range, 42V transient - Core: ARM processor - Memory：128 KB flash, 16KB SRAM - ADC: Up to 6 channels, 10-bit resolution, Up to 3.6MSPS - PWM: Up to 6-channel PWM, up to 288MHz PWM clock - High accuracy current sense with ±0.75% precision(vs ±1%) - V, I , Phase & Differential five Demodulation output - Integrates 2 Pairs Half-Bridge Driver - Two high-precision QDT method available, fit for various coil structure - Integrated high precision frequency detection - Multi-Driver Speed Selectable for better EMI - 5mmx4mm QFN48 | Products > Wireless Charger > Wireless Charging Transmitter > |
